Preformed Reinforcing Armor Rods Preformed splice / Preformed Grip for guy wire or other cable.

Table Selection of Preformed Armor Rods for ACSR Remark: Material of Preformed Armor Rods for ACSR is aluminum alloy wire;

Use and structure: The preformed armor rods are used to keep the conductor from the vibration, clamp compressive stress, friction and abrasion, electric arc and other damages. The structure of the preformed armor rods andpreformed short armor rods is simple and a set of preformed rods become an empty pipe and enlace, holdand protect the conductor.

The product is suitable for the standard preformed rods for ACSR; It alwaysinstalled in the ship-type suspension clamp and support insulators. And it will not be used in splice or repairsleeve.

Trait: 1)The preformed rods holding the conductor tightly, avoid slip of conductor, and so that minimized theabrasion of conductor. 2)Due to the grip flexibility of preformed rods, it will keep the conductor from loosen. 3)The raw material have been sealed with stainless, so that to keep excellent corrosion resistance. 4) Installed by hand directly, no need special tool. 5)Easy to guarantee the quality of installation, checked by optic view without special training. 6) The preformed rods is a very common fitting, it can be matched with different clamps.
